Dynamic CCTV EZ960 - POS Setup (Versatile H.264 DVR Only); POS Function; POS Overlay; Exception POS Setup

OSD Setup Manual
60
POS Setup (Versatile H.264 DVR Only)
The <POS> function is only available for Versatile H.264 DVR. It provides a connection
between a DVR and a Point-of-Sale equipment, such as cash registers. With this function,
the financial transaction data can be linked to specific camera images and recorded to the
DVR. To enable this function, enter OSD setup menu and select <POS>. Press Enter and
the menu will be shown as follows. Items in this menu are described in the following
subsections.
POS
POS Function
POS Overlay
Exception POS Setup
Input Setup
On
Live & PB
< POS Function >
This item is used to enable/disable this function. Select <On>, the text database will be
created on the hard disk.
< POS Overlay >
This item is for users to choose which mode users want to display the POS overlay on the
monitor. Select <Live> to display the POS overlay in Live mode only; select <PB> to display
the POS overlay in Playback mode only; and select <Live & PB> to display in both modes.
NOTE: POS overlay only shows in full screen mode.
NOTE: PB overlay is available only under x1 playback speed.
< Exception POS Setup >
This sub-menu is used to define the conditions that will be treated as an “Exception” and
thus trigger an action (the function will be implemented later).
Exception POS Setup
Exception No.
Trigger
Exception String
By Numerals
Value
Value (Upper Limit)
1
On
NO SALE
OFF
