< Per Camera Config >
This sub-menu is used to set the Day / Night / Weekend PPS and recording quality for each
individual channel. <Preset Configuration> must be set to <OFF> in order to access these
related settings. The menu is displayed as below.
Per Camera Config
Cameral Select
Normal PPS
Normal Qlty
Event Max PPS
Event Qlty
Event Act
Day
30
Mid
30
Best
Both
Night
30
Mid
30
Best
Both
CH01
Weekend
30
Mid
30
Best
Both
 Camera Select
The item is used to select a desired channel for setting the parameters. Move the
cursor to <Camera Select> and press ENTER, then select a channel using UP /
DOWN keys. Press ENTER again to confirm the selection.
 Normal PPS
<Normal PPS> is used to set the recording rate for normal status. Please note that
the normal PPS for each channel cannot exceed 30 for NTSC / 25 for PAL.
 Normal Qlty
This item is used to set the picture size for normal status recording. The available
options are: <Low>, <Fair>, <Mid>, <High> and <Best>.
 Event Max PPS
<Event Max PPS> is used to set the event recording rate for Event status. Usually,
the Event PPS is set equal to or greater than the Normal PPS. The setting is
depending on users’ application. If the Event PPS is set to <0>, the DVR will not
record event video when alarms triggered.
 Event Qlty
This item is used to set the picture size for event status recording. The available
options are: <Low>, <Fair>, <Mid>, <High> and <Best>.
 Event Active
Users are allowed to choose which alarm type needs to be recorded. The available
options are <Alarm> (alarm events only), <Motion> (motion detection events only)
and <Both> (alarm event + motion detection), and <None>. The default setting is
<Both>, which includes Alarm and Motion events recording.
