OSD Setup Manual
23
- UPnP
Set the first item UPnP to <ON> and the DVR is now with UPnP function.
- UPnP NAT Traversal
The UPnP NAT traversal function will help to automatically setup a router
if the DVR connects to the internet via a router. Select <Yes> and the
settings of router will be taken care by the DVR itself.
< RS485 Setup >
This menu allows users to setup the parameters of the DVR’s RS-485 communication port.
From System Setup, select <RS485 Setup> and press ENTER. The following menu is
displayed.
RS485 Setup
Unit ID
Baud Rate
Bits
Stop
Parity
224
9600
8
1
None
 Unit ID
This item is used to change the RS-485 ID address of the DVR. The ID is in the
range of <1> to <255>.
 Baud Rate
The Baud rate options for associated with the protocol are <2400>, <4800>,
<9600>, <19200>, <38400>, and <57600>.
 Bits
Users can specify the bits in a word associated with this protocol. The available
options are <6>, <7> and <8> bits.
 Stop
Users can specify the stop bit associated with this protocol. Options are <1> and
<2> stop bits.
 Parity
This item is used to specify the parity associated with this protocol. Options are
<Odd>, <Even> and <None>.
