User’s Manual
53
Exit CMS System
Click on the Power button and select <Exit> to close CMS.
Minimize CMS Main Window
Click on the Power button and select <Minimize> to minimize CMS main
window. CMS can be minimized to the tray icon or to the taskbar button. Refer
to section PC System Info, for more information.
6.2 Display Mode
The available display modes are single channel, 4-windows, 9-windows,
16-windows, 25-windows, 36-windows, 49-windows, 64-windows, 8-windows,
10-windows and 13-windows. Click on any icon to view the selected display
mode. To view in single channel, double click on the channel in the site tree or
on the grid.
NOTE: When the display is in single channel and the resolution is set
to higher than D1, the ratio of length/width of the displayed image will
be fixed.
Displaying Color of Camera Titles
There are three different displaying colors for camera titles Red, White, and
Green. The following chart shows the meaning of three different colors.
Red The connected site is a DVR currently recording.
White
CMS is remotely playing back videos from connected sites.
In addition, icons Sequence, Full screen, Last mode, Page up and Page down
give users variable options in monitor surveillance.
Sequence
Click on the <Sequence> icon to start sequence display of cameras added in
the sequence list. The initial display mode will be what was set in sequence
setting (1*1, 2*2, 3*3, 4*4 or 5*5). Refer to section Sequence Setting for
details about sequence setups.
