The EZ960 16 channel DVR range are low in price but big on features. Offering easy to use functions such as the EZ record function users
can easily set the amount of days they want the DVR to record for and it will set itself up accordingly. Added to this is the easy backup
function which allows for start and end point along with your selection of channel and an avi option for easy playback. With BNC, HDMI &
VGA outputs for monitors and real-time recording at 960h resolution the EZ960 DVRs are a fantastic option for most installs. Other
fantastic features include built in EZ DDNS eliminating the need for a static IP number, a programmable spot monitor output and audio
recording on all channels.
FEATURES:
Ÿ Built in USB/DVD for back up with ezBurn technology
allowing playback software to be burned onto back up
Ÿ Remote viewing via TCP/IP also allowing remote viewing
via Gigabit ethernet
Ÿ ezRecord allowing you to easily specify the amount of
days to record for
Ÿ Covert Facility, 5 record settings, auto sequencing
Ÿ Smart cell motion detection with selectable areas
Ÿ Multiple built in dome protocols for PTZ control
Ÿ 16 Channel Quadplex recording
Ÿ Alarms In/Out, OSD & Time and Date
Ÿ 16 channel audio recording
Ÿ HDMi as standard with full 1080P output
Ÿ VGA & BNC outputs
Ÿ Multi screen display
Ÿ Pre alarm recording
Ÿ Powerful H264 recording
Ÿ Infra Red remote control
Ÿ USB mouse control
Ÿ Fanless design allowing install into almost any situation
Ÿ 960h realtime recording
Ÿ BNC Loop through
Dimensions
Unit: mm (inch)
DISPLAY
EZ960
Input BNCx16,1.0Vp-p,
75ohm
CALL Monitor BNC x 1, 1.0Vp-p, 75ohm
HDMi 1024x768, 1280x1024, 1920x1080p
VGA 1024x768, 1280x1024, 1280 x 720, 1920 x 1080
Picture Refresh Rate 25 PPS/per-channel
AUDIO
Input D-SUBx16
Output D-SUB x 1, Line-out
Compression Method G.711
Data Rate 64 Kbit/s, per CH
RECORDING
Compression Method H.264 High profile
Recording Mode Schedule, Alarm, Motion Detection
Pre-alarm Yes
Recording 960 x 576 @25 fps
Resolution Rate 720 x 576 @25 fps
720 x 288 @25 fps
H.264 WD1 400pps
Recording Quality 8 Levels Presets, Adjustable
Storage Mode Linear / Circular
Data Lifetime Yes (Programmable)
STORAGE
HDD Interface 2x SATA
4TB each
DVD+RW DVD
Export x 2 USB 2.0 Port, Supports ThumbDrive, 1 DVD rewriter
ALARM
Alarm Input x 16, D-SUB,
line in
Alarm Relay Output x 1, D-SUB, line out
Alarm Detection N.C. / N.O., Programmable
Motion Detection 16 x 12 Grid Array, Sensitivity, Trigger level adjustable
Video Loss Detection Programmable
COMMUNICATION
Network Connectivity RJ45, 10/100/1000 Mbps Ethernet
Remote Control Software CMS, Internet Explorer
Remote Operation Monitoring, Playback, Recording, System setup, Dome
camera control, Archiving
RS-485 D-SUB
Dome Camera Control Protocol DSCP, Pelco P, Pelco D, AD422, Fastrax 2, Panasonic, JVC
GENERAL
Operation System Embedded (Linux)
Unit Dimension (W x H x D) 440 x 55 x 360 mm (17.3" x 2.1" x 14.1")
Unit Weight 3.5 Kg
Operation Temperature 0 °C ~ 40 °C (32 °F ~ 104 °F)
Relative Humidity 10% ~ 90%, Non-condensing
Power Consumption DC 12V, 60W, Power adaptor
Network
Software
16chAudio
Max 8TB
HDD
Remote
PTZ Use
Web Use
H.264
Codec
1080P
Hi Res
Mouse
HDMi
Focus
Iris
Zoom
Esc
Call
Copy
PTZ
+ + +---
Mode
Play
Freez
Sequence Search Menu
Power Alarm LAN REC
EZ
16
HDHD
1 2 3
4
5
6
7
8
9 10 11 12 13 14 15 16
LAN
AUDIO VGA
I/O
DIGITAL
OUTPUT
USB
VGA BNC
CALL
MONITOR
MAIN
MONITOR
CH1
CH3 CH5
CH1 CH4 CH6
CH7 CH9 CH11 CH13 CH15
CH8 CH10
CH12 CH14 CH16
DC12V
440 (17.3")
55 (2.2")
Dynamic
CCTVLtd
Works
on
APPLE
OSX
9B/9C Bowes Rd, Riverside Park, Middlesbrough, TS2 1LU
www.dynamic-cctv.com
sales@dynamic-cctv.com TEL:01642 220166
Fanless
We use
Surveillance HDDs
16CH
Backup
360 (14.1")
EZ960/16
