F15 Series Fetal & Maternal Monitor User Manual Fetal Monitoring
- 91 -
This product is designed for use with the introducer.
3) Using aseptic technique, remove the catheter from the package.
4) Perform vaginal exam to ensure ruptured membranes and adequate dilation.
5) Advance the catheter tip to the cervical os along the examination hand, using the hand as a
guide. Do not advance the introducer through the cervix.
6) Continue to gently advance the catheter tip through the cervical os and feed the catheter
into the intra-amniotic cavity until the 45 cm mark is at the introitus. If the 45cm mark is not
clearly visible, stop advancing when the symbol on the catheter meets the introducer.
NOTE:
For easier insertion, do not twist the catheter in the introducer.
7) The IUPC may be spontaneously filled with amniotic fluid. This can be seen in the clear
lumen of the catheter. The filter cap will prevent the amniotic fluid from leaking.
8) Slide the introducer out of the vagina along the catheter. When the introducer is completely
out of the vagina, slide thumb between catheter and introducer tab, which will begin to
separate the introducer from the catheter.
Figure 7-9 Separate the Introducer
9) Anchor the catheter in place with one hand, and pull the introducer straight back off the
catheter.
Figure 7-10 Remove the Introducer
10) Remove the liner from the adhesive pad, and then adhere the pad to the patient’s skin.
Secure the catheter by placing the catheter attachment strap to the adhesive pad.
Figure 7-11 Secure the Adhesive Pad to Mother
Rezeroing the System during Monitoring
With the catheter connected to the DECG-IUP integrated cable, momentarily adjust the monitor to
zero by pressing AUTO ZERO key.
