F15 Series Fetal & Maternal Monitor User Manual Basic Operation
- 46 -
from the monitor.
3.6.3.4 *Reviewing
The reviewing keys (backward key) and
(forward key) are used to review the traces. The word REVIEW is shown in the background when
reviewing the traces.
Select the backward key to review the previous traces. The traces start to retreat. The amount of the
progress symbol “<” on top of the traces indicates the retreating speed. Touch the symbol to
increase the speed until it reaches the maximum. Touch the symbol to decrease the speed until
it reaches the minimum. Touch any place of the trace window on the screen to pause.
Select the forward key to review the next traces. The traces start to advance. The amount of the
progress symbol “>” on top of the traces indicates the advancing speed. Touch the symbol to
increase the speed until it reaches the maximum. Touch the symbol to decrease the speed
until it reaches the minimum. Touch any place of the trace window on the screen to pause.
When the reviewing is paused, the progress symbol turns to <--X%-->. If the PRINT key is pressed at
this moment, the recorder will print the traces starting from the left edge of the screen at a high speed.
X% indicates the proportion of current traces positioned in the whole reviewable traces.
Touch any place out of the trace window on the screen to return to the real-time main interface. If no
operation is performed in 10 seconds, the monitor switches to real-time interface automatically, unless
the printing is in process.
When reviewing the traces, the monitor does not stop. The FH sound and numerics are all real time
information of the current patient.
WARNING
The reviewing printout is provided for reference only. Please take the real-time printout as
criterion when making diagnoses.
NOTE:
1 The main interface only displays traces and patient information of one file. If you want to
review another file you should search for the file and load it.
2 For a real-time monitoring patient, you can print all her traces, including SpO2 trace.
However, when printing traces in a file, the SpO2 trace cannot be printed.
3 You must pause before printing starts. Printing in the process of playback might result in
failure information on the paper.
4 After the reviewed data has been printed out, the recorder does not switch back to real-time
printing automatically.
3.6.3.5 *CTG Analysis
CTG analysis aims at a real-time trace, providing some reference data for the physicians. It only
analyzes the real-time trace after its been printed for 10 minutes, and the longest duration is 60
minutes.
WARNING
1 CTG analysis is used for the surveillance of pregnancies and not in delivery room of
Traditional 510(k) of Fetal & Maternal Monitor
014_14.1_F15_Series_User_Manual
62202
