EDAN F15 Series User Manual

F15 Series Fetal & Maternal Monitor User Manual Basic Operation
- 21 -
Figure 3-10 Front View and Back View of the Wireless FECG Fetal&Maternal Module
Figure 3-11 ECG Leads Socket
The wireless FECG Fetal&Maternal Module is used with ECG leads and monitor eFHR, HR and
uterine activity through FECG techonology, uterine activity can also be monitored through the
pressure sensor.
3.2.2 Remote Event Marker(Optional for F15 Only)
The remote event marker is a hand-held device operated by pregnant woman herself. Press the
button on the remote event marker when feeling fetal movement.
Figure 3-12 Remote Event Marker
1
2
1 Marker Plug
2 Press Key
Screen
Belt Button
Symbols
Pressure
Sensor
Traditional 510(k) of Fetal & Maternal Monitor
014_14.1_F15_Series_User_Manual
37／202
