F15 Series Fetal & Maternal Monitor User Manual Product Specificaiton
- 141 -
A1.8 Interface Specifications
A1.8.1 USB Interfaces
Number of USB Interfaces
Standard: 2
Drive Mode
HOST interface, USB 2.0 protocol
Power Supply
5 .3VDC±5%, 1500 mA Max.
Interface Type
USB A-type port
A1.8.2 Wired Network Interface
Specification
100-Base TX (IEEE802.3)
Interface Type
Standard RJ-45 network interface
A1.8.3 HDMI Interface
Number of HDMI Interface
1
Interface Type
HDMI
A1.8.5 DB15 Interface
Specification
RS-485 signal
pin4､pin6 to pin9
RS-232 signal
pin2､pin3
UART signal
Pin10､pin14､pin15
FHR analog signal
input
pin1､pin11
Power signal
pin5､pin12
Interface Type
DB-15 female receptacle
Traditional 510(k) of Fetal & Maternal Monitor
014_14.1_F15_Series_User_Manual
157／202
