EDAN F15 Series User Manual

F15 Series Fetal & Maternal Monitor User Manual Product Specificaiton
- 133 -
Weight
◆Wireless transducer≤150g
◆Wired transducer≤150g (not including the wire)
Cable Length
2.5m
Shock Resistance
Withstands a 1.5 m drop at least 3 times to concrete surface with
possible cosmetic damage only
FECG Fetal&Maternal Module
Dimension
86±3mm(L)×61±3mm(W)×26±3mm(H)
Weight
< 150g (not including the wire)
Screen Size
0.96 inches
Screen Resolution
128×64 (Pixels)
FT20 Telemetry Transmitter
Dimension
139mm(L)×68mm(W)×28mm(H)
Weight
<260g
Screen Size
0.96 inches
Shock Resistance
Withstands a 1.5 m drop at least 3 times to concrete surface with
possible cosmetic damage only
Coupling Gel
pH
Acoustic Impedance
1.5x10
6
Pa.s/m ~1.8x10
6
Pa.s/m (35°C/95ºF)
A1.3 Performance Specifications
FHR
Technique:
Ultrasound Pulse Doppler with autocorrelation
*FHR Measurement Range
50 bpm ~ 240 bpm
Resolution
1 bpm
*Accuracy
±2 bpm
FHR Ultrasound Signal
Range
3.5uV Vpp~350 uV Vpp
*Alarm
FHR Alarm
Pulse Repetition Rate:
(2+10%)KHz
Pulse Duration:
(92+10%) µs
Ultrasound Frequency:
(1.0±10%) MHz
Ultrasound Signal Range:
3.5uV Vpp~350 uV Vpp
Traditional 510(k) of Fetal & Maternal Monitor
014_14.1_F15_Series_User_Manual
149／202
