F15 Series Fetal & Maternal Monitor User Manual Alarms
- 57 -
MAP Alarm Delay
0 second, not adjustable
0 second
MAP Alarm Priority
Medium, not adjustable
Medium
TEMP Alarm
On, Off
On
TEMP Low Alarm Limit
0 ºC ~ +49.9 ºC, in increments of 0.1
+36.0 ºC
TEMP High Alarm Limit
+0.1 ºC ~ +50.0 ºC, in increments of 0.1
+39.0 ºC
TEMP Alarm Delay
0 second, not adjustable
0 second
TEMP Alarm Priority
Medium, not adjustable
Medium
NOTE:
The upper limit must be higher than the lower limit. When setting the upper limit, you do not
have access to the options that are lower than the preset lower limit, and vice versa.
4.18 Alarm Messages
4.18.1 Fetal Monitoring Alarm Messages
During fetal monitoring, the monitor gives alarms for the situations that need the physicians to pay
attention to. The alarm messages are listed below.
Patient Alarm Messages
Alarm Message
Cause
Countermeasure
Medium Priority
**FHR1 HIGH or
** FHR1 xxx > yyy,
**FHR2 HIGH or
** FHR2 xxx > yyy
**FHR3 HIGH or
** FHR3 xxx > yyy
**DFHR HIGH or
**DFHR xxx > yyy
**eFHR HIGH or
**eFHR xxx > yyy
FHR1, FHR2, FHR3, DECG or
FECG measuring result (xxx)
is higher than the set upper
limit (yyy) and the alarm delay
time of the upper limit is out.
Check if the alarm limits are suitable;
check the patient’s condition.
**FHR1 LOW or
** FHR1 xxx < yyy,
**FHR2 LOW or
** FHR2 xxx < yyy
**FHR3 LOW or
** FHR3 xxx < yyy
**DFHR LOW or
**DFHR xxx < yyy
**eFHR LOW or
**eFHR xxx < yyy
FHR1, FHR2, FHR3, DECG or
FECG measuring result (xxx) is
lower than the set lower limit
(yyy) and the alarm delay time
of the lower limit is out.
Traditional 510(k) of Fetal & Maternal Monitor
014_14.1_F15_Series_User_Manual
73／202
