F15 Series Fetal & Maternal Monitor User Manual Troubleshooting
- 145 -
Inconstant trend
The DECG cable has not been
fixed firmly
Fix an attachment pad at the
DECG cable.
A3.7 Troubles with Contractions Monitoring (External)
Phenomenon
Possible Cause
Solution
Bad trace quality or
fluctuant TOCO baseline
The belt is too tight or too loose.
Adjust the belt.
The belt has no elasticity.
Renew the belt.
Maternal movement.
Request the patient to calm
down and stay still.
Frequent fetal movements.
Delay the monitoring.
Too high TOCO
sensitivity (higher than
100 unit)
The body pressure from uterus to
TOCO transducer is far higher
than the average numeric.
Insure favorable contact for
patient skin with TOCO
transducer. Change the position
of TOCO transducer, if
necessary.
A3.8 Troubles with Contractions Monitoring (Internal)
Phenomenon
Possible Cause
Solution
No trend
The intrauterine catheter is
jammed
Wash with disinfector
No pressure change
when uterine contraction
“Dry” environment or the tip of
intrauterine catheter is placed
extraovularly
Wash with disinfector or change
the position of transducer
Only see the IUP peak
but no baseline
Zero adjustment is wrong
Zero the system
The trend is a beeline
The connector failure.
Move or contact catheter. If
trend no fluctuation, change
intrauterine cable.
A3.9 Trouble with ECG Monitoring
Phenomenon
Possible Cause
Solution
Big ECG signal
interference or thick
baseline
Abnormal electrodes placing or
electrodes invalidation.
Check the electrodes placing and
the period of validity of
electrodes.
The cable connector is not well
connected.
Check the connection of cable
connector.
Power socket has no standard
ground wire.
Check if power socket has
standard ground wire.
Traditional 510(k) of Fetal & Maternal Monitor
014_14.1_F15_Series_User_Manual
161／202
