3.2.3 DECG Cable
Figure 3-13 DECG Cable
3.2.4 DECG-IUP Integrated Cable
Figure 3-14 DECG-IUP Integrated Cable
3.2.5 Fetal Spiral Electrode
Figure 3-15 Fetal Spiral Electrode
1
Reference Electrode
2
Drive Tube
3
Guide Tube
4
Drive Handle
5
Handle Notch
6
Electrode Wire
7
Safety Cap
1
2
1 Interface to DECG-IUP integrated cable
2 DECG cable plug
1
1 Interface to IUP catheter
2 Interface to TOCO transducer
3 Interface to DECG cable
3
2
