F15 Series Fetal & Maternal Monitor User Manual Basic Operation
- 24 -
3.2.9 NIBP Cuff
Figure 3-19 NIBP Cuff Figure 3-20 Cuff Extension Tube
3.2.10 TEMP Sensor
Figure 3-21 TEMP Transducer
3.3 FT20 Telemetry Transmitter
Figure 3-22 FT20 Telemetry Transmitter
Figure 3-23 Socket of FT20 Telemetry Transmitter
The FT20 Telemetry Transmitter supports wireless measurement of maternal NIBP and SpO2.
1
2
2
1
1 NIBP Cuff
2 Inflation Tube Connector
3 Cuff Extension Tube
1 TEMP Connector
2 TEMP Sensor
Screen
Power
Key
Charging
Interface
NIBP
Socket
SpO2
Socket
3
