F15 Series Fetal & Maternal Monitor User Manual Troubleshooting
- 146 -
The special ground wire
connecting with monitor is not
properly earthed.
Check if the special ground wire
connecting with monitor is
earthed.
Inconstant trace
/ display
Improper positions of ECG
electrodes
Place the ECG electrodes per
suggested positions.
Poor contact between ECG
electrodes and the skin
Change the ECG electrodes and
attach them to the body
A 3.10Troubles with HR Monitoring with Electrode Sleeve
Phenomenon
Possible Cause
Solution
Weak ECG signal
The angle of the transducer is
not appropriate
Rotate the transducer slightly in
the left and right 90° range until a
clear ECG signal is found
The placement location is not
optimal
Select the upper, flat area of the
fundus as much as possible
The belt is too loose or the signal
of the patient herself is too weak
Adjust the belt and transducer, if
no improvements are made,
change another method of
detection when ECG calculation is
doubtful.
Big ECG signal
interference or thick
baseline
Bad contact between
electrodes and skin
Ensure the three electrodes are in
complete contact with the skin
Dry or rough skin of the patient
Prepare the skin and remove skin
scurf and grease with medical
alcohol cotton or wet tissue. Avoid
using conductive substance that is
easy to make residual such as
conductive paste in case of short
circuit between electrodes.
Patient sweats
Clean the skin regularly and keep
it dry
Patients’ movements and
changes of abdomen profile that
lead to bad contact of electrodes
Suggest the patient to move less,
and adjust the belt and transducer
while changing position, and
ensure electrodes are in contact
The special ground wire
connecting with monitor is not
properly earthed.
Check if the special ground wire
connecting with monitor is
earthed.
The power socket of the monitor,
infusion pump that connects to
the patient or electric delivery
bed doesn’t have standard
ground wire
Check if power socket has
standard ground wire.
Traditional 510(k) of Fetal & Maternal Monitor
014_14.1_F15_Series_User_Manual
162／202
