F15 Series Fetal & Maternal Monitor User Manual Product Specificaiton
- 137 -
(2.7kPa~31.3 kPa)
*Alarm
Systolic pressure, Diastolic pressure, Mean
pressure Alarm
Software Over Voltage
Protection
(297  3) mmHg [(39.6  0.4) kPa]
Hardware Over Voltage
Protection
(320  10) mmHg [(42.81.3) kPa]
Unit
mmHg, kPa
Measurement Methods
Auto, Manual
PR Measurement
* Range:40bpm ~ 240bpm
* Accuracy: ±3 bpm or 3.5%, whichever is greater
Resolution: 1bpm
*Limits of the error of the
manometer
Over the temperature range of 10 °C to 40 °C and
the relative humidity range of 15 % to
85 %(non-condensing), the maximum error for
the measurement of the CUFF pressure at any
point of the NOMINAL measurement range shall
be less than or equal to ± 3 mmHg (± 0,4 kPa) or
2 % of the reading, whichever is greater.
TEMP
Channel
1
*Measurement Range
0°C ~ +50°C
Resolution
0.1°C
*Accuracy
At 25°C ~45°C, the measurement accuracy is
0.2°C.
Other measuring range, the measurement
accuracy is 0.3°C.
The accuracy of this part consists of two parts, as
follows:
(1) Accuracy (without sensor error): ±0.1℃
(2) Sensor error: ±0.1°C at 25°C~45°C; ±0.2°C at
other measurement ranges
Unit
°C , ℉
Refresh Time
1 ~ 2s
Alarm Limits
0.0℃ ~ +50.0℃
*Alarm
TEMP Alarm
Position
Axilla
Transient Response Time
≤30 s
Measuring Mode
Direct Mode
FECG
eFHR
Traditional 510(k) of Fetal & Maternal Monitor
014_14.1_F15_Series_User_Manual
153／202
