F15 Series Fetal & Maternal Monitor User Manual WI-FI Networking and Instructions
- 176 -
6
Other interference
Bluetooth, zigbee,
cordless phone,
walkie-talkie, etc.
Bluetooth, zigbee, wireless
phones, interphones need to be
more than 20cm away from the
monitor, microwave ovens and so
on need to be more than 1m
away. These devices will reduce
the SNR of Wi-Fi
Required to meet.
7
Bandwidth
The average throughput
requirement for a single monitor is
330 kbps, and a 50% throughput
derating is recommended. For
example, if there are 16 monitors
that require 5.3 Mbps of
bandwidth, the monitor needs to
plan for at least 10 Mbps
throughput.
Required to meet.
8
Ping Delay and Jitter
Ping the monitor from the central
station, confirm the delay is less
than 500ms, the jitter is less than
100ms
It needs to be tested when other
equipments in the hospital are
running.
Required to meet.
Please pay attention that Edan recommends to use AP DLINK DAP2230 for Wi-Fi networking
between monitor and central station, and the signal strength observed on the monitor end should be
no less than -45dB.
The observation interface: MenuSystem SetupNetworking Setup
Traditional 510(k) of Fetal & Maternal Monitor
014_14.1_F15_Series_User_Manual
192202
