F15 Series Fetal & Maternal Monitor User Manual Basic Operation
- 41 -
The numeric list can be reviewed: select the list, press the symbol to review the
previous lists.
Besides the fetal numerics, the numeric window of F15 includes maternal vital signs: SpO
2
, NIBP, HR
and TEMP:
Figure 3-35 Maternal Monitoring Numerics
99: Current SpO
2
measurement numeric.
: SpO
2
indicator.
SI: Signal intensity.
14:23: Time when the NIBP measurement starts.
From left to right, top to bottom in turn: current systolic
pressure (117), mean artery pressure (89) and diastolic
pressure (75) and PR (57).
(manual): The current NIBP measurement mode is manual.
