SERIAL COMMUNICATION PROTOCOL
5
Example:
TMS temperature: 0046
hex
= 70 ºC (158ºF)
Motor temperature: 0014
hex
= 20 ºC (68ºF)
Motor current: 19
hex
= 2.5A
Measured rotational speed: 017C
hex
= 380 Hz = 22,800 rpm
Control unit temperature: 0032
hex
= 50 °C
Parameter
1
ASCII
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
HEX
Parameter
1
2
ASCII
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
0
0
4
6
HEX
30
30
34
36
Parameter
3
4
5
6
7
ASCII
0
0
1
4
*1
*1
1
9
*1
*1
*1
*1
*1
*1
0
1
7
C
HEX
30
30
31
34
31
39
30
31
37
43
Parameter
8
9
ASCII
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
0
0
3
2
HEX
30
30
33
32
*1 System reservation
