ESR series service routers.ESR-Series. User manual
113
Step Description Command Keys
esr(config-gi)# switchport
general
Only for
ESR-1000/1200/1500/1511/1700.
This mode is the default mode and is
not displayed in the configuration.
8 Configure VLAN list on the
interface in tagged mode.
esr(config-if-gi)# switchport
trunk allowed vlan add <VID>
Only for ESR-10/12V(F)/14VF/
15/20/21/30/100/200/3100/3200.
<VID> – VLAN identifier, set in the
range of [2..4094].
It is also possible to create multiple
vlan (with a comma) or vlan range
(with a hyphen).
esr(config-if-gi)# switchport
general allowed vlan add <VID>
tagged
For ESR-1000/1200/1500/1511/1700.
<VID> – VLAN identifier, set in the
range of [2..4094].
It is also possible to create multiple
vlan (with a comma) or vlan range
(with a hyphen).
9 Configure VLAN on the interface
in tagged mode (optional).
esr(config-if-gi)# switchport
trunk native-vlan <VID>
Only for ESR-10/12V(F)/14VF/
15/20/21/30/100/200/3100/3200.
<VID> – VLAN identifier, set in the
range of [2..4094].
esr(config-if-gi)# switchport
general allowed vlan add <VID>
untagged
For ESR-1000/1200/1500/1511/1700.
<VID> – VLAN identifier, set in the
range of [2..4094].
10 Enable the processing of Ethernet
frames of all created VLANs on
the interface (optional).
esr(config-if-gi)# switchport
trunk allowed vlan auto-all
Only for ESR-10/12V(F)/14VF/
15/20/21/30/100/200/3100/3200.
esr(config-if-gi)# switchport
general allowed vlan auto-all
Only for
ESR-1000/1200/1500/1511/1700.
11 Set VLAN port identifier (PVID) for
incoming untagged traffic
(optional).
esr(config-if-gi)# switchport
general pvid <PVID>
Only for
ESR-1000/1200/1500/1511/1700.
