ELTEX ESR-3100 User Manual

ESR series service routers.ESR-Series. User manual
64
Table 33 – Rear panel connectors description
№ Description
1 Earth bonding point of the device.
ESR-12V side panels
The side panel layout of ESR-12V is depicted in figures 45 and 46.
Figure 45 – ESR-12V left side panel
Figure 46 – ESR-12V right side panel
Side panels of the device have air vents for heat removal. Do not block air vents. This may cause the
components to overheat, which may result in device malfunction. For recommendations on device installation,
see section Installation and connection.
2.4.12 ESR-10 design
ESR-10 rear panel
The rear panel layout of the device is depicted in figure 47.
Figure 47 – ESR-10 rear panel
Table 34 lists connectors, LEDs and controls located on the rear panel of ESR-10.
