ELTEX ESR-3100 - Configuration Example

ESR series service routers.ESR-Series. User manual
556
•
•
•
•
•
•
Step Description Command Keys
12 Change the number of failed data-link
tests before breaking the session
(optional).
esr(config-pppoe)# ppp
failure-count <NUM>
<NUM> – the number of failed data-
link tests, specified in the range
[1..100].
Default value: 10.
13 Change the time interval in seconds
after which the router sends a
keepalive message (optional).
esr(config-pppoe)# ppp
timeout keepalive <TIME >
<TIME> – time in seconds, takes
values of [1..32767].
Default value: 10.
14 Override the MSS (Maximum segment
size) field in incoming TCP packets
(optional).
esr(config-pppoe)# ip tcp
adjust-mss <MSS>
<MSS> – MSS value, takes values in
the range of [500..1460].
Default value: 1460.
15 Enable recording of the current tunnel
usage statistics (optional).
esr(config-pppoe)# history
statistics
It is also possible to configure the PPPoE client:
QoS in basic or advanced mode (see section QoS management);
proxy (see section HTTP/HTTPS traffic proxying);
Traffic monitoring (see sections Netflow configuration andsFlow configuration);
15.4.2 Configuration example
Objective:
Configure PPPoE client on the router.
Accounts for connection – tester;
Account passwords – password;
The connection should be established from the gigabitethernet 1/0/7 interface.
