ESR series service routers.ESR-Series. User manual
•
•
will be returned. Also a set of three-digit numbers starting with '1', the Invite of which will be sent
to 10.110.60.51 IP address and 5060 port, will be returned.
Example 7: (S3 *xx#|#xx#|#xx#|*xx*x+#) – management and the use of VAS.
Local calls inside the device may be required in some cases. If the device’s IP address is not
known or is periodically changed, it is convenient to use the reserved word {local} as the server
address, which means sending the corresponding sequence of digits to the device’s own address.
Example: (123@{local}) – call on number 123 will be locally processed within the device.
19.8 FXO port configuration
Objective:
Add the ability to make a call to PSTN subscriber through the ESR-12V FXO port.
Solution:
Enable FXO port:
esr(config)# interface voice-port 4
Specify FXO port number same as PSTN access prefix:
esr(config-voice-port-fxo)# sip user phone 9
Specify UDP port from which and to which the FXO set will send and receive SIP messages:
esr(config-voice-port-fxo)# sip port 5064
Specify a displayed name:
esr(config-voice-port-fxo)# sip user display-name user-one
Configure login and password for authentication:
esr(config-voice-port-fxo)# authentication name login-9
esr(config-voice-port-fxo)# authentication password superpassword
Assign SIP profile to FXO port:
esr(config-voice-port-fxo)# profile sip 1
Enable the number transmission to PSTN:
esr(config-voice-port-fxo)# pstn transmit-number
Disable prefix transmission:
esr(config-voice-port-fxo)# no pstn transmit-prefix
For outgoing calls to work, specify the following rule in the dial plan settings, which means that outgoing calls
to numbers with prefix 9 are routed locally to the FXO set:
9x.@{local}:5064
