4.2 Types and naming procedure of router interfaces
Network interfaces of various types and purposes are used for the router operation. The naming system allows
you to uniquely address the interfaces by their functional purpose and location in the system. The following
table contains the list of interfaces types.
Table 55 – Types and naming procedure of router interfaces
Interface type Designation
Physical interfaces Designation of physical interface includes its type and identifier.
The identifier of physical interfaces is as follows: <UNIT>/<SLOT>/
<PORT>, where
<UNIT> – number of a device in a device group,
<SLOT> – device module number or '0' if the device does not
consist of modules,
<PORT> – port sequence number.
1Gbps ports gigabitethernet <UNIT>/<SLOT>/<PORT>
Designation example: gigabitethernet 1/0/12
10Gbps ports tengigabitethernet <UNIT>/<SLOT>/<PORT>
Designation example: tengigabitethernet 1/0/2
40Gbps ports fortygigabitethernet <UNIT>/<SLOT>/<PORT>
Designation example: fortygigabitethernet 1/0/2
Channel aggregation groups Designation of channel aggregation group includes its type and
identifier:
port-channel <CHANNEL_ID>
Designation example: port-channel 6
It is permitted to use short name, for example, gi1/0/12.

It is permitted to use short name, for example, te1/0/2.

It is permitted to use short name, for example, fo1/0/2.

It is permitted to use short name, for example, po1.

