ELTEX ESR-3100 User Manual

ESR series service routers.ESR-Series. User manual
539
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
15 Remote access configuration
Configuring server for remote access to corporate network via PPTP protocol
Configuration algorithm
Configuration example
Configuring server for remote access to corporate network via L2TP protocol
Configuration algorithm
Configuration example
Configuring server for remote access to corporate network via OpenVPN protocol
Configuration algorithm
Configuration example
Configuring remote access client via PPPoE
Configuration algorithm
Configuration example
Configuring remote access client via PPTP
Configuration algorithm
Configuration example
Configuring remote access client via L2TP
Configuration algorithm
Configuration example
15.1 Configuring server for remote access to corporate network via PPTP protocol
PPTP (Point-to-Point Tunneling Protocol) is a point-to-point tunneling protocol that allows a computer to
establish secure connection with a server by creating a special tunnel in a common unsecured network. PPTP
encapsulates PPP frames into IP packets for transmission via global IP network, e.g. the Internet. PPTP may
be used for tunnel establishment between two local area networks. РРТР uses an additional TCP connection
for tunnel handling.
15.1.1 Configuration algorithm
Step Description Command Keys
1 Create PPTP server profile. esr(config)# remote-access pptp
<NAME>
<NAME> – PPTP server profile
name, set by the string of up to 31
characters.
2 Specify the description of the
configured server (optional).
esr(config-pptp-server)#
description <DESCRIPTION>
<DESCRIPTION> – PPTP server
description, set by the string of up
to 255 characters.
