Create a static route to the remote LAN. For each subnet located beyond the IPsec tunnel, specify a
route via VTI tunnel:
esr(config)# ip route 192.0.2.0/24 tunnel vti 1
Create IKE protocol profile. Select Diffie-Hellman group 2, AES 128 bit encryption algorithm and MD5
authentication algorithm in the profile. The given security parameters are used for IKE connection
protection:
esr(config)# security ike proposal ike_prop1
esr(config-ike-proposal)# dh-group 2
esr(config-ike-proposal)# authentication algorithm md5
esr(config-ike-proposal)# encryption algorithm aes128
esr(config-ike-proposal)# exit
Create IKE protocol policy. For the policy, specify the list of IKE protocol profiles that may be used for
node and authentication key negotiation:
esr(config)# security ike policy ike_pol1
esr(config-ike-policy)# pre-shared-key hexadecimal 123FFF
esr(config-ike-policy)# proposal ike_prop1
esr(config-ike-policy)# exit
Create IKE protocol gateway. For this profile, specify VTI tunnel, policy, protocol version and mode of
traffic redirection into the tunnel.
esr(config)# security ike gateway ike_gw1
esr(config-ike-gw)# ike-policy ike_pol1
esr(config-ike-gw)# mode route-based
esr(config-ike-gw)# bind-interface vti 1
esr(config-ike-gw)# version v2-only
esr(config-ike-gw)# exit
Create security parameters profile for IPsec tunnel. For the profile, select Diffie-Hellman group 2, AES
128 bit encryption algorithm and MD5 authentication algorithm. Use the following parameters to secure
IPsec tunnel:
esr(config)# security ipsec proposal ipsec_prop1
esr(config-ipsec-proposal)# authentication algorithm md5
esr(config-ipsec-proposal)# encryption algorithm aes128
esr(config-ipsec-proposal)# exit
Create a policy for IPsec tunnel. For the policy, specify the list of IPsec tunnel profiles that may be used
for node negotiation:
esr(config)# security ipsec policy ipsec_pol1
esr(config-ipsec-policy)# proposal ipsec_prop1
esr(config-ipsec-policy)# exit
