Specify 192.168.100.1/30 address and the 'LAN' zone for the gi1/0/2 interface. R1 will be connected to R2
device via the given interface for the further traffic routing:
esr(config)# interface gi1/0/2
esr(config-if-gi)# security-zone LAN
esr(config-if-gi)# ip address 192.168.100.1/30
esr(config-if-gi)# exit
Specify 128.107.1.2/30 address and the 'WAN' zone for the gi1/0/3 interface. R1 interface will be connected to
the Internet via this interface:
esr(config)# interface gi1/0/3
esr(config-if-gi)# security-zone WAN
esr(config-if-gi)# ip address 128.107.1.2/30
esr(config-if-gi)# exit
Create a route for interaction with 10.0.0.0/8 network using R2 device as a gateway (192.168.100.2):
esr(config)# ip route 10.0.0.0/8 192.168.100.2
Create a route for interaction with the Internet using the provider gateway as a nexthop (128.107.1.1):
esr(config)# ip route 0.0.0.0/0 128.107.1.1
Specify the device name for R2 router:
esr# hostname R2
Specify 10.0.0.1/8 address and the 'LAN' zone for the gi1/0/1 interface. R2 interface will be connected to
10.0.0.0/8 network via this interface:
esr(config)# interface gi1/0/1
esr(config-if-gi)# security-zone LAN
esr(config-if-gi)# ip address 10.0.0.1/8
esr(config-if-gi)# exit
Specify 192.168.100.2/30 address and the 'LAN' zone for the gi1/0/2 interface. R2 will be connected to R1
device via the given interface for the further traffic routing:
esr(config)# interface gi1/0/2
esr(config-if-gi)# security-zone LAN
esr(config-if-gi)# ip address 192.168.100.2/30
esr(config-if-gi)# exit
