Configuration on ESR:
ESR
ESR# config
ESR(config)# mpls
ESR(config-mpls)# forwarding interface gigabitethernet 1/0/1
ESR(config-mpls)# ldp
ESR(config-ldp)# router-id 1.1.1.1
ESR(config-ldp)# enable
ESR(config-ldp)# address-family ipv4
ESR(config-ldp-af-ipv4)# interface gigabitethernet 1/0/1
ESR(config-ldp-af-ipv4-if)# end
ESR#
Configuration on ESR1:
ESR1
ESR1# configure
ESR1(config)# mpls
ESR1(config-mpls)# forwarding interface gigabitethernet 1/0/1
ESR1(config-mpls)# ldp
ESR1(config-ldp)# router-id 4.4.4.4
ESR1(config-ldp)# enable
ESR1(config-ldp)# address-family ipv4
ESR1(config-ldp-af-ipv4)# interface gigabitethernet 1/0/1
ESR1(config-ldp-af-ipv4-if)# end
ESR1#
Check:
Enter the following commands at one of the peers:
ESR# show mpls ldp discovery detailed
Local LDP ID: 1.1.1.1
Discovery sources:
 Interfaces:
  gigabitethernet 1/0/1:
        Hello interval: 5 seconds
  Transport IP address: 1.1.1.1
  LDP ID: 4.4.4.4
   Source IP address: 10.10.10.2
   Transport IP address: 4.4.4.4
             Hold time: 15 seconds
             Proposed hold time: 90/15 (local/peer) seconds
The output will show the parameters of the neighboring peer obtained from the multicast hello messages.
