One of the following commands can be used to check the LDP convergence:
ESR1# show mpls ldp neighbor
Peer LDP ID: 2.2.2.2; Local LDP ID 1.1.1.1
State: Operational
TCP connection: 2.2.2.2:33933 - 1.1.1.1:646
Messages sent/received: 1059/1070
Uptime: 17:32:07
LDP discovery sources:
gigabitethernet 1/0/1.10
Peer LDP ID: 4.4.4.4; Local LDP ID 1.1.1.1
State: Operational
TCP connection: 4.4.4.4:40894 - 1.1.1.1:646
Messages sent/received: 1376/1386
Uptime: 22:38:38
LDP discovery sources:
gigabitethernet 1/0/1.40
MP-BGP configuration
Create VRF on ESR1 and ESR3, respectively. Specify RD, rt-export/import in accordance with the
scheme.Configure interface for interaction with CE (CE-SiteA и CE-SiteB).Additionally, create a route-map to
allow BGP route announcements:
ESR1
ESR1(config)# ip vrf Customer1
ESR1(config-vrf)# ip protocols bgp max-routes 1000
ESR1(config-vrf)# rd 65500:100
ESR1(config-vrf)# route-target import 65500:100
ESR1(config-vrf)# route-target export 65500:100
ESR1(config-vrf)# exit
ESR1(config)# interface gigabitethernet 1/0/2
ESR1(config-if-gi)# ip vrf forwarding Customer1
ESR1(config-if-gi)# description "Customer1"
ESR1(config-if-gi)# ip firewall disable
ESR1(config-if-gi)# ip address 192.168.32.1/30
ESR1(config-if-gi)# exit
ESR1(config)# route-map OUTPUT
ESR1(config-route-map)# rule 1
ESR1(config-route-map-rule)# action permit
ESR1(config-route-map-rule)# exit
ESR1(config-route-map)# exit
ESR1(config)# do commit
ESR1(config)# do confirm
Without specifying RD and RT attributes the route information will not get into the VPNv4 table.

