ESR series service routers.ESR-Series. User manual
437
*GRE tunnel configuration*
ESR2# sh tunnels configuration
Tunnel State Description
---------------- -------- ------------------------------
gre 1 Enabled --

ESR2# sh tunnels configuration gre 1
State: Enabled
Description: --
Mode: ip
Bridge group: --
VRF: --
Local address: 192.0.2.2
Remote address: 192.0.2.1
Calculates checksums for outgoing GRE packets: No
Requires that all input GRE packets were checksum: No
key: 60
TTL: 64
DSCP: Inherit
MTU: 1472
Path MTU discovery: Enabled
Don't fragment bit suppression: Disabled
Security zone: --
Multipoint mode: Disabled
Keepalive:
State: Disabled
Timeout: 10
Retries: 6
Destination address: --

*vpnv4 routes presence*
SR2# sh bgp vpnv4 unicast all
Status codes: * - valid, > - best, i - internal, S - stale
Origin codes: i - IGP, e - EGP, ? - incomplete

Codes Route Distinguisher IP Prefix Next hop Metric Label LocPrf
Weight Path
----- --------------------- ------------------ --------------- ---------- ------- ----------
------ ----------------
*> 65500:1 10.101.0.0/24 -- -- 34 100 --
65502 i
*>i 65500:1 10.100.0.0/24 10.12.0.1 -- 16 100 0
65501 i

*LDP state*
ESR2# sh mpls ldp neighbor
Peer LDP ID: 10.12.0.1; Local LDP ID 10.12.0.2
State: Operational
TCP connection: 10.12.0.1:646 - 10.12.0.2:46444
Messages sent/received: 60/60
Uptime: 00:53:59
LDP discovery sources:
gre 1
ESR2# sh mpls forwarding-table
Local Outgoing Prefix Outgoing Next Hop
label label or tunnel ID Interface
-------- -------- ------------------------------------------- ----------------
---------------------------------------
