ELTEX ESR-3100 User Manual

ESR series service routers.ESR-Series. User manual
593
Step Description Command Keys
3 Set the interval after which the
information on active sessions is
exported to the collector.
esr(config)# netflow active-
timeout <TIMEOUT>
<TIMEOUT> – delay before sending
active sessions information, set in
seconds, takes the value of
[5..36000].
Default value: 1800 seconds.
4 Set the interval after which the
information on outdated sessions is
exported to the collector.
esr(config)# netflow inactive-
timeout <TIMEOUT>
<TIMEOUT> – delay before sending
outdated sessions information, set
in seconds, takes the value of
[0..240].
Default value: 15 seconds.
5 Set the rate of the statistics
sending to a Netflow collector.
esr(config)# netflow refresh-rate
<RATE>
<RATE> – rate of the statistics
sending, set in packets/flow, takes
the value of [1..10000].
Default value: 10.
6 Enable Netflow on the router. esr(config)# netflow enable
7 Create the Netflow collector and
switch to its configuration mode.
esr(config)# netflow collector
<ADDR>
<ADDR> – collector IP address,
defined as AAA.BBB.CCC.DDD
where each part takes values of
[0..255].
8 Set the Netflow service port on the
statistics collection server.
esr(config-netflow-host)# port
<PORT>
<PORT> – UDP port number in the
range of [1..65535].
Default value: 2055.
9 Enable statistics sending to the
Netflow server in the interface/
tunnel/network bridge configuration
mode.
esr(config-if-gi)# ip netflow
export
