ELTEX ESR-3100 User Manual

ESR series service routers.ESR-Series. User manual
635
Step Description Command Keys
5 Configure a login for
authentication.
esr(config-voice-port-fxs)#
authentication name
<LOGIN>
<LOGIN> – login for authentication, set by
the string of up to 31 characters
6 Configure a password for
authentication.
esr(config-voice-port-fxs)#
authentication password
<PASS>
<PASS> – authentication password, set by
the string of up to 16 characters.
7 Enable FXO port. esr(config)# interface voice-
port <NUM>
<NUM> – FXO port number, takes values
of [1..4].
8 Assign a subscriber number
reserved for a telephone port.
esr(config-voice-port-fxo)#
sip user phone <PHONE>
<PHONE> – subscriber number reserved
for a telephone port.
9 Specify UDP port from which and
to which the FXO set will send and
receive SIP messages.
esr(config-voice-port-fxo)#
sip port <PORT>
<PORT> – UDP port number.
10 Assign the user name matched
with the port.
esr(config-voice-port-fxo)#
sip user display-name
<LOGIN>
<LOGIN> – user name displayed in the
Display-Name field, set by the string of up
to 31 characters.
11 Configure a login for
authentication.
esr(config-voice-port-fxo)#
authentication name
<LOGIN>
<LOGIN> – login for authentication, set by
the string of up to 31 characters.
12 Configure a password for
authentication.
esr(config-voice-port-fxo)#
authentication password
<PASS>
<PASS> – authentication password, set by
the string of up to 16 characters.
13 Enable the number transmission
to PSTN.
esr(config-voice-port-fxo)#
pstn transmit-number
14 Disable prefix transmission. esr(config-voice-port-fxo)#
no pstn transmit-prefix
15 Enable the 'Hostline PSTN to IP'
service.
esr(config-voice-port-fxo)#
hotline ipt
16 Number of the subscriber that will
receive calls from PSTN.
esr(config-voice-port-fxo)#
hotline number ipt <PHONE>
<PHONE> – phone number that calls are
made to when using the service, takes the
value from 1 to 50.
'Hot/Warm line' in the direction from
analogue telephone line to VoIP.
