№ Front panel
element
Description
Power Device power LED.
Master Failover mode operation LED (is not supported in the current version).
Fan Fan operation LED.
RPS Redundant power supply LED.
2 Console Console port RS-232 for local management of the device.
3 OOB Ethernet port for router management.
4 SD SD-card connector.
5 USB1 Port for USB device connection.
6 F Functional key that reboots the device and resets it to factory default configuration:
Pressing the key for less than 10 seconds reboots the device;
Pressing the key for more than 10 seconds resets the terminal to factory settings.
7 USB2 Port for USB device connection.
8 Ethernet 4 ports of Ethernet 10/100/1000BASE-T.
9 Combo
Ports [1 .. 4]
4 ports of Gigabit Ethernet 10/100/1000BASE-X (SFP).
10 XG1 – XG4 Slots for 10G SFP+/1G SFP transceivers.
