6
Data preparation
6.18
Training manual • Basic training • Status 03.14
EOS P 396
• In the Perforation group box enter if necessary the properties of the hole and
the web for the sinter box.
Using the Next or Skip button move on to the next step of the Sinterbox
Wizard.
The Sinterbox Step 3 of 3: Labeling window appears.
• In the Parameters group box enter the depth and the spacing for the lettering.
• In the Direction group box select the position of the label.
• In the Text group box enter the label text or automatically label with the
name of the part using the Part Names button.
• Using the Font button set the required font type, size and face.
4. Generate sinter box:
Click Finish button.
