EOS P 396 - Correcting Part-Specific Shrinkage; Setting Part-Specific Beam Offset

Operation of machine & accessories
7.11
Training manual • Basic training • Status 03.14
EOS P 396
7
Correcting part-specific shrinkage
Due to special part properties, a part can be allocated a part-specific shrinkage in
addition to the material-specific shrinkage. It can therefore also be necessary to
scale the part.
☞ Operation EOS P 396 manual, section 6, Correcting part-specific shrinkage.
Setting part-specific beam offset
By changing the beam offset for individual parts, these parts can be allocated a
specific undersize or oversize. This action is necessary for special applications, e.g.
for a fit. For this purpose the required part or several parts must be selected and the
required value for the beam offset entered.
☞ Operation EOS P 396 manual, section 6, Setting part-specific beam offset.
➢ Using a part-dependent scaling, the part can be scaled in the X and Y
direction, however not in the Z direction.
➢ Part-dependent scaling values are added to the material-dependent scaling
values:
- The sum of the scaling values is indicated in the Job parameters window
in the Scaling column of the list of parts.
- The value entered for a selected part is indicated in the Job parameters
window, Setting tab, Part scaling group box.
If several parts are marked, a value is not indicated.
Use this PSW functionality very carefully to avoid mistakes.
The value entered for the part-dependent beam offset for a selected part is
indicated in the Job parameters window, Setting tab, Part-specific undersize /
oversize group box.
If several parts are marked, a value is not indicated.
Use this PSW functionality very carefully to avoid mistakes.
