3
Layout, function of ma
chine and accessories
3.6
Training manu
al • Basic
training • Status 03.14
EOS P 396
Front of switching cabinet, open
2
1
3
4
5
7
8
9
6
10
1
Controller
2
Circuit breakers
3
Motor cut-outs
4
Steppe
r motor f
inal sta
ges with
integrated PLC (Posimo)
5
Laser power supply unit
6F
u
s
e
s
7
Eurotherm universal regulators
Process chamber
8
Eurotherm universal regulators
Removal chamber
9
Exposure hours counter
10
Process computer
39
