Epson Stylus COLOR 3000 Service Manual

Adjustment
EPSON Stylus Color 3000 Service Manual
4-6
Determining the Printhead ID
Normally, printhead IDs cannot be determined without removing the printhead. However, the adjustment
program is designed to read printhead voltage data stored in the EEPROM on the main control board. This
section describes how to find out the printhead voltage, which contains the printhead ID.
1. Connect the printer to the host computer with a parallel interface cable.
2. Run the adjustment program on the host computer.
3. Enter the market setting (Refer to page 4-4).
4. Select Adjustment & Check from the main menu. Press Enter; the Adjustment & Check menu appears.
5. Select A4 and press Enter; the printer prints an A4 check pattern. See the paragraph under 6. TITLE; the
printhead voltages are printed in 8 digits, shown in bold letters in the example below:
Look at the 2nd line, which shows the black printhead voltage (
BK
) and the color printhead voltage
(
YMC
). The 2nd and 3rd digits show the printhead ID for normal dot, and the 5th digit shows the rank
value. The last 2 digits show the printhead ID for micro dot, as shown below:
[Black printhead]
18
: Printhead ID for normal dot
2
: Rank value
16
: Printhead ID for micro dot
[Color printhead]
16
: Printhead ID for normal dot
2
: Rank value
15
: Printhead ID for micro dot
6. Omit the “0”s from the printhead voltage to get the printhead ID, as shown below:
Black printhead ID (
BK
): 18216
Color printhead ID (
YMC
): 16215
6. TITLE
Rev. A <2> For C206. (011)=<000000>CLB 0 CLC 0
BK
:( )=<
01802016
>
YMC
: ( )=<
01602015
> 01-03-01980 22:10:19 No.

Epson Stylus COLOR 3000 Specifications

Printing Resolution

maximum resolution	1440 x 720 dpi
driver setting resolution	720 x 720 dpi
printable width	410 mm

Paper Handling

paper capacity (plain paper)	100 sheets
paper capacity (EPSON Inkjet transparencies)	30 sheets
paper capacity (envelopes)	10 envelopes

Ink Cartridges

black ink cartridge print capacity	Up to 3, 000 pages (A4, text @ 360dpi)
colour ink cartridges print capacity	Up to 2, 100 pages (A4, 360dpi 5% duty each colour)
colour ink cartridges	Cyan, Magenta, Yellow

Operating Environment

operating temperature	10-35°C
operating humidity	20-80% RH
total print volume	75, 000 pages (A3, text only)

Electrical Specifications

rated voltage	AC 220V-240V
rated frequency	50-60 Hz
power consumption	Approx. 21W (ISO 10561 letter pattern)

Weight and Dimensions

weight	18 Kg
width	810 mm
depth	565 mm
height	240 mm
