Paper Feeding
Paper transport method Friction feed with built-in auto sheet feeder (ASF)
Line spacing 1/6 inch, 1/8 inch or programmable at 1/360 inch
Paper path

Cut-sheets ASF (Front entry)

Continuous paper Rear tractor

Banner paper Rear banner roll holder
Feeding speed 100 msec per line (1 line = 1/3 inch)
4.0 inches per second
Paper Handling & Specifications
Width Length
Statement 5.5 in. (139.7 mm) 8.5 in. (215.9 mm)
A5 5.8 in. (148 mm) 8.3 in. (210 mm)
B5 7.2 in. (182 mm) 10.1 in. (257 mm)
Executive 7.3 in. (184.2 mm) 10.5 in. (266.7 mm)
A4 8.3 in. (210 mm) 11.7 in. (297 mm)
Letter 8.5 in. (215.9 mm) 11.0 in. (279.4 mm)
Legal 8.5 in. (215.4 mm) 14.0 in. (355.6 mm)
B4 10.1 in. (257 mm) 14.3 in. (364 mm)
ANSI B 11 in. (279.4 mm) 17 in. (431.8 mm)
A3 11.7 in. (297 mm) 16.5 in. (420 mm)
A3 wide 13.0 in. (329 mm) 19.0 in. (483 mm)
A2 16.5 in. (420 mm) 23.4 in. (594 mm)
Paper
ANSI C 17.0 in. (431.8 mm) 22.0 in. (558.8 mm)
Paper Thickness
0.0031 in. (0.08 mm) to 0.0059 in. (0.15 mm)
Paper Weight
ASF 17 lb (64 g/ m
2
) to 24 lb (90 g/ m
2
)
Manual insertion 14 lb (52 g/ m
2
) to 24 lb (90 g/ m
2
)
Quality
Epson special media, Bond paper
Notes:
1. Be sure to use the designated side of exclusive paper.
2. Make sure that the paper has no creases, curls, or tears.
3. When inserting paper, use the marks on the case as a guide, and push the paper in until it meets
resistance. When placing paper in an ASF, be sure not to overload it.
Width Length
Letter 8.5 in. (215.9 mm) 11 in. (279.4 mm)
Size
A4 8.3 in. (210 mm) 11.7 in. (297 mm)
Paper Thickness
0.003 in. (0.075 mm) to 0.0033 in. (0.085 mm)
Note: Print on the designated side of transparency paper and at normal temperatures.
Table 1-5. Cut Sheet Specifications
Table 1-6. Transparency Specifications
