Epson Stylus COLOR 3000 Service Manual

Product Description
EPSON Stylus Color 3000 Service Manual
1-20
Device ID
The printer sends following device ID strings upon request:
 [00H] [xxH]
 MFG EPSON
 CMD ESCPL2, PRPXL, BDC
 MDL Stylus COLOR 3000
 CLS PRINTER
Note: [00H] denotes a hexadecimal value of zero.
Macintosh Serial Interface
Standard
RS-423 compliant
Synchronization
Synchronous
Bit rate
Approximately 900 Kbps, 1.8 Mbps
Word format
Start bit1 bit
Data bit 8 bit
Parity bit No parity bit
Stop bit 1 bit
Handshaking
X-ON/X-OFF, DTR protocol
Adaptable connector
8-pin mini circular connector
Recommended I/F cable
Apple System Peripheral-8 cable
Pin No. Signal Name I/O Function Description
1 SCLK O Synchronous clock
2 CTS I Clear to send
3 TxD- O Transmit data -
4 S.G. I Signal Ground
5 RxD- I Receive data -
6 TxD+ O Balanced Transmit +
7 DTR O Data terminal ready
8 RxD+ I Balanced Receive +
State Buffer space X-ON/X-OFF DTR
Busy Less than 1024 bytes Send X-OFF code Off
Ready More than 2048 bytes Send X-ON code On
Table 1-23. Connector Pin Assignments for the Serial Interface
Table 1-24. X-ON/X-OFF, DTR Protocol

Epson Stylus COLOR 3000 Specifications

Printing Resolution

maximum resolution	1440 x 720 dpi
driver setting resolution	720 x 720 dpi
printable width	410 mm

Paper Handling

paper capacity (plain paper)	100 sheets
paper capacity (EPSON Inkjet transparencies)	30 sheets
paper capacity (envelopes)	10 envelopes

Ink Cartridges

black ink cartridge print capacity	Up to 3, 000 pages (A4, text @ 360dpi)
colour ink cartridges print capacity	Up to 2, 100 pages (A4, 360dpi 5% duty each colour)
colour ink cartridges	Cyan, Magenta, Yellow

Operating Environment

operating temperature	10-35°C
operating humidity	20-80% RH
total print volume	75, 000 pages (A3, text only)

Electrical Specifications

rated voltage	AC 220V-240V
rated frequency	50-60 Hz
power consumption	Approx. 21W (ISO 10561 letter pattern)

Weight and Dimensions

weight	18 Kg
width	810 mm
depth	565 mm
height	240 mm
