Epson Stylus COLOR 3000 Service Manual

EPSON Stylus COLOR 3000
EPSON Stylus Color 3000 Service Manual
3
-3
3.2 Disassembly and Assembly
Read the CAUTION on page 3-1 prior to disassembling the printer.
CAUTION
Upper Housing
Removal
ROM Replacement
Printer Mechanism
Removal
Printhead Removal
HP Sensor Removal
PWS Paper Width
Sensor Removal
Main Board Removal
PSB/PSE Board
Removal
PL Sensor Removal
Waste Ink Drain
Pad Removal
Printer Mechanism
Disassembly
CR Unit Removal
LD Roller Shaft
Removal
PF Roller Shaft
Removal
Rear Paper Guide
Removal
Middle Frame
Assembly Removal
Ink Cartridge Holder
Removal
Ink End Sensor
Removal
Cartridge Sensor
Removal
Edge Guide Unit
Removal
Paper Quantity Sensor
Removal
Release Sensor
Removal
Front/Rear PE Sensor
Removal
CR Motor Removal
Pump Motor Removal
Paper Eject Frame
Removal
Pump Unit Removal
ASF PW Sensor
Removal
PF Motor Removal
Start
Figure 3-1. Printer Disassembly Procedures

Epson Stylus COLOR 3000 Specifications

Printing Resolution

maximum resolution	1440 x 720 dpi
driver setting resolution	720 x 720 dpi
printable width	410 mm

Paper Handling

paper capacity (plain paper)	100 sheets
paper capacity (EPSON Inkjet transparencies)	30 sheets
paper capacity (envelopes)	10 envelopes

Ink Cartridges

black ink cartridge print capacity	Up to 3, 000 pages (A4, text @ 360dpi)
colour ink cartridges print capacity	Up to 2, 100 pages (A4, 360dpi 5% duty each colour)
colour ink cartridges	Cyan, Magenta, Yellow

Operating Environment

operating temperature	10-35°C
operating humidity	20-80% RH
total print volume	75, 000 pages (A3, text only)

Electrical Specifications

rated voltage	AC 220V-240V
rated frequency	50-60 Hz
power consumption	Approx. 21W (ISO 10561 letter pattern)

Weight and Dimensions

weight	18 Kg
width	810 mm
depth	565 mm
height	240 mm
