Epson Stylus COLOR 3000 Service Manual

Product Description
EPSON Stylus Color 3000 Service Manual
1-16
Physical Specifications
 Weight 49.6 lb (22.5 Kg)
 Dimensions 31.9 in (W) × 22.2 in (D) × 9.4 in (H)
(810 mm × 565 mm × 240 mm)
Refer to the Appendix for details.
1.4 Interfaces
The EPSON Stylus COLOR 3000 is equipped with parallel and Macintosh serial interfaces and a card slot for
an optional Type-B interface. This section provides information on each interface.
Parallel Interface
Forward Channel

Transmission mode
8 bit parallel, IEEE-1284 compatibility mode

Synchronization
By /STROBE pulse

Handshaking
By /BUSY and /ACKNLG signal

Signal level
TTL compatible

Adaptable connector
57-30360 (Amphenol) or equivalent
Parameter Minimum Maximum Condition
VOH* - 5.5 V
VOL* -0.5 V -
IOH* - 0.32 mA VOH = 2.4 V
IOL* - 12 mA VOL = 0.4 V
CO - 50 pf
VIH - 2.0 V
VIL 0.8 V -
IIH - 0.32 mA VIH = 2.0 V
IIL - 12 mA VIL = 0.8 V
CI - 50 pf
∗ A LOW logic level on the Logic H signal is as follows:
2.0 V or less when the printer is turned off.
3.0 V or more when the printer is turned on.
The receiver provides an impedance equivalent to 7.5 K ohms to ground.
The BUSY signal is set HIGH before setting either /ERROR LOW or PE HIGH, and held HIGH until these
signals return to an inactive state. The BUSY signal is HIGH:
 During data entry.
 When the input data buffer is full.
 While /INIT signal is at LOW level or during hardware initialization.
 During a printer error condition (See /ERROR signal).
 During test printing.
 When the printer is in default setting mode.
Table 1-18. Signal level of TTL Compatible (IEEE-1284 level 1 device)

Epson Stylus COLOR 3000 Specifications

Printing Resolution

maximum resolution	1440 x 720 dpi
driver setting resolution	720 x 720 dpi
printable width	410 mm

Paper Handling

paper capacity (plain paper)	100 sheets
paper capacity (EPSON Inkjet transparencies)	30 sheets
paper capacity (envelopes)	10 envelopes

Ink Cartridges

black ink cartridge print capacity	Up to 3, 000 pages (A4, text @ 360dpi)
colour ink cartridges print capacity	Up to 2, 100 pages (A4, 360dpi 5% duty each colour)
colour ink cartridges	Cyan, Magenta, Yellow

Operating Environment

operating temperature	10-35°C
operating humidity	20-80% RH
total print volume	75, 000 pages (A3, text only)

Electrical Specifications

rated voltage	AC 220V-240V
rated frequency	50-60 Hz
power consumption	Approx. 21W (ISO 10561 letter pattern)

Weight and Dimensions

weight	18 Kg
width	810 mm
depth	565 mm
height	240 mm
