Pin No. I/O Signal Name Description
1 I GAP Platen gap sensor signal
2

GND Ground
Pin No. I/O Signal Name Description
1

+ 5 + 5 VDC
2

GND Ground
3 I ASF_PQ ASF PQ sensor signal
Pin No. I/O Signal Name Description
1 I ASF_PL0 ASF PL sensor signal
2

GND Ground
3 I ASF_PL1 ASF PL sensor signal
4

GND Ground
5 I ASF_PL2 ASF PL sensor signal
6

GND Ground
Pin No. I/O Signal Name Description
1 I IC_Y0 Ink cartridge sensor signal
2

GND Ground
3 I IC_Y1 Ink end sensor signal
4

GND Ground
Pin No. I/O Signal Name Description
1 I IC_C0 Ink cartridge sensor signal
2

GND Ground
3 I IC_C1 Ink end sensor signal
4

GND Ground
Pin No. I/O Signal Name Description
1 I IC_B0 Ink cartridge sensor signal
2

GND Ground
3 I IC_B1 Ink end sensor signal
4

GND Ground
Table A-8. Connector Pin Assignments (CN9)
Table A-9. Connector Pin Assignments (CN10)
Table A-10. Connector Pin Assignments (CN11)
Table A-11. Connector Pin Assignments (CN12)
Table A-12. Connector Pin Assignments (CN13)
Table A-13. Connector Pin Assignments (CN14)
