Epson Stylus COLOR 3000

Appendix
EPSON Stylus Color 3000 Service Manual
A-3
Pin No. I/O Signal Name Description
1 I REL Release sensor signal
2

GND Ground
Pin No. I/O Signal Name Description
1 I PE_F Front PE sensor signal
2

GND Ground
Pin No. I/O Signal Name Description
1 I PE_R Rear PE sensor signal
2

GND Ground
Pin No. I/O Signal Name Description
1 I HP HP sensor signal
2

+ 5 + 5 VDC
3

GND Ground
Pin No. I/O Signal Name Description
1 I IC_M0 Ink cartridge sensor signal
2

GND Ground
3 I IC_M1 Ink end sensor signal
4

GND Ground
Pin No. I/O Signal Name Description
1

NC

2 I ASF_PW ASF PW sensor signal
3

+ 5 + 5 VDC
4

GND Ground
5

NC

Table A-2. Connector Pin Assignments (CN3)
Table A-3. Connector Pin Assignments (CN4)
Table A-4. Connector Pin Assignments (CN5)
Table A-5. Connector Pin Assignments (CN6)
Table A-6. Connector Pin Assignments (CN7)
Table A-7. Connector Pin Assignments (CN8)
