Epson Stylus COLOR 3000

Appendix
EPSON Stylus Color 3000 Service Manual
A-21
A.5 Dimensions and Weight
 Dimension 31.8 in (W) ×22.2 in (D) × 9.4 in (H)
810 mm (W) × 565 mm (D) × 240 mm (H)
 Weight 49.6 lb (22.5 Kg)
Figure A-16 illustrates the exterior dimension of the Stylus COLOR 3000.
385 mm (15.1")
434 mm (17.0")
565 mm (22.2")
380 mm (14.9")
793 mm (31.2")
810 mm (31.8")
240 mm
(9.4")
Figure A-16. Dimensions of the Stylus COLOR 3000
