Epson Stylus COLOR 3000 Service Manual

EPSON Stylus COLOR 3000
EPSON Stylus Color 3000 Service Manual 1-29
Black and White Printing CMYK Printing (color)
Auto  Good throughput and print
quality.
 Good throughput.
 Low color quality when using special paper.
(Color correction depends on the print direction.)
Bi-D  High throughput.
 Possibly low print quality.
 High throughput.
 Low color quality when using special paper.
(Color correction depends on the print direction.)
Uni-D  Low throughput.
 High print quality.
 Low throughput.
 High color quality.
Character Mode
(for DOS)
Raster Graphics Mode
(for Windows / Macintosh)
*
ESC U 0 Auto Bi-D
Auto ESC U 1 Auto Uni-D
ESC U 2 Auto Auto

Auto Auto
ESC U 0 Bi-D Bi-D
Default
Bi-D ESC U 1 Uni-D Uni-D
Setting Mode
ESC U 2 Auto Auto

Bi-D Bi-D
ESC U 0 Uni-D Bi-D
Uni-D ESC U 1 Uni-D Uni-D
ESC U 2 Uni-D Auto

Uni-D Uni-D
*The driver in the Windows or Macintosh environment controls printing direction.
When banner mode is selected by a default setting or remote command, the function works as described in
Table 1-33.
Function
Trigger
Banner mode Off
(manual insertion)
Banner mode On
Command
FF 1. Page length is set by ESC (C
→ Eject
2. Page length is not set by ESC (C
→ Advances to the top margin of
the next page
Advances to the top margin of the
next page.
ESC EMR No operation No operation
Switch
FF Eject Advances to the top margin of the
next page.
Eject Eject (maximum 44 inches) Advances to the top margin of the
next page.
Data
Over the page
length set by
command
1. If page length is set by ESC (C
→ Eject
2. If page length is not set by ESC (C
→ No operation
No operation
Over the paper
length
Eject Eject
Table 1-31. Print Direction Mode Characteristics
Table 1-32. Printing Direction and ESC U Commands
Table 1-33. Vertical Printing Positions for Manual Insertion

Epson Stylus COLOR 3000 Specifications

Printing Resolution

maximum resolution	1440 x 720 dpi
driver setting resolution	720 x 720 dpi
printable width	410 mm

Paper Handling

paper capacity (plain paper)	100 sheets
paper capacity (EPSON Inkjet transparencies)	30 sheets
paper capacity (envelopes)	10 envelopes

Ink Cartridges

black ink cartridge print capacity	Up to 3, 000 pages (A4, text @ 360dpi)
colour ink cartridges print capacity	Up to 2, 100 pages (A4, 360dpi 5% duty each colour)
colour ink cartridges	Cyan, Magenta, Yellow

Operating Environment

operating temperature	10-35°C
operating humidity	20-80% RH
total print volume	75, 000 pages (A3, text only)

Electrical Specifications

rated voltage	AC 220V-240V
rated frequency	50-60 Hz
power consumption	Approx. 21W (ISO 10561 letter pattern)

Weight and Dimensions

weight	18 Kg
width	810 mm
depth	565 mm
height	240 mm
