EPSON Stylus Color 3000 Service Manual
3
-13
Type-B I/F Board Guide
Grounding Contact for Type-B
Interface Board Guide
CBS Screws (3×8)
Main Board
ASF PW Sensor Connector Cable
ASF PL Sensor Connector Cable
CN8
CN15
CN11
CN17
CP Screws (3×6)
Lower Housing
Upper Connector Cover
CBS Screw (3×8)
CBS Screws
(3×8)
CBS Screw (3×8)
CBS Screw (3×8)
CBS Screws (3×8)
Control Panel Cable
PSB/PSE Board
Connector Cable
Figure 3-10. C203 Main Board Removal
