Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 255
Confidential
DISASSEMBLY FLOWCHART
A1
E1
B1
F1
C1
Start
Rear Back Cover
(→P. 256)
Start
Rear Upper Cover Assy
(→P. 257)
Housing ASF
(→P. 259)
Printer Cover
(→P. 259)
Housing Right
(→P. 260)
A3
D1
A2
E2
B2
F2
C2
D2
Paper Guide
(→P. 258)
B3
E3 F3D3
E4 F4D4
Ink Eject Cover
(→P. 260)
E5 F5D5
E6 F6
ASF Cover
(→P. 257)
D6
Housing Left
(→P. 261)
E7 F7
Housing Top
(→P. 261)
F8E8
Cover Open Sensor
(→P. 262)
F9
C3
Paper Guide
(→P. 258)
C4
C5
Housing Rear
(→P. 258)

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
