Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 346
Confidential
DISASSEMBLY FLOWCHART
Rear Cover (Back)
(→P. 347)
A1
C1
B1
Start
Start
ASF Front Cover
(→P. 347)
Housing Left
(→P. 348)
Ink Eject Cover
(→P. 350)
Housing Right
(→P. 350)
Cable Guide
(→P. 352)
Housing Upper
(→P. 351)
ADF/SCN Unit
(→P. 353)
Hinge Assy
(→P. 354)
Hinge Lower Cover
(→P. 354)
Relay Board Assy
(→P. 348)
A4
A2
C2
B2
A3
C3
B3
C4
B4
C5
B5
C6
B6
C8
C9
C10
Speaker Assy
(→P. 351)
B7
Rear ASF Assy
(→P. 355)
PS Ground Plate
(→P. 356)
Rear ASF Upper Guide
Assy (→P. 356)
C12
C13
C11
Power Supply Assy
(→P. 357)
C14
C H E C K
P O I N T
 As for the procedure indicated by , refer to 6.2.4.4
Housing (WF-C5200 Series) (2) (p. 254) in the case of
the WF-C5200 Series, and remove the parts from the
Rear Back Cover to the Housing Top.
 The procedure indicated by is applicable only in the
WF-C5700 Series/ET-8700.
C7

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
