Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 390
Confidential
DISASSEMBLY FLOWCHART
Preparation for
Dissembling
Ink Discharge
(→P. 391)
A1
D1
B1
Start
Rear Cover (Back)
(→P. 392)
Start
ASF Front Cover
(→P. 393)
Ink Eject Cover
(→P. 393)
Housing Right
(→P. 394)
Housing Left
(→P. 394)
Housing Upper
(→P. 395)
Extension Spring 11.11
(→P. 396)
B9
C1
A2
D2
B2
C2
A3
D3
B3
C3
A4
D4
B4
C4
A5
D5
B5
C5
A6
D6
B6
C6
B8
CR Scale
(→P. 397)
A8
Head Upper Cover
(→P. 397)
C8 D8
Ink Supply Tube
(→P. 398)
C10
Plate
(→P. 398)
D9
C H E C K
P O I N T
 As for the procedure indicated by , refer to 6.2.4.4
Housing (WF-C5200 Series) (2) (p. 254) in the case of
the WF-C5200 Series, and remove the parts from the
Rear Back Cover to the Housing Top.
 The procedure indicated by is applicable only in the
WF-C5700 Series/ET-8700.
 Implement the procedure indicated by when
removing the Ink Tube from the RIPS Unit and
Printhead.
Seal Joint Head
(→P. 402)
D11
C9
D10
ADF/SCN Unit
(→P. 395)
A7
D7
B7
C7
