Customizing
label
The total thickness of the label must not exceed 125µm (microme-
ters). Do not use either stiff materials or glues.
Before starting to insert the customized label, see
“Chapter 29 ->
Inserting customized labels“
.
Position Function - Dimensions L x H (mm)
1 ESA Logo, VT Model - 101 x 13
2 F-key customization F - 118 x 18
3 Customizing label for command and/or signal elements - 112 x 8
4 F-key customization E - 149 x 16
